ITT Cannon, LLC DCMN8C8PNA191
- Mfg. Part Number
- DCMN8C8PNA191
- Manufacturer
- ITT Cannon, LLC
- Product Category
- D-Sub Connectors
- Brief Description
- D-Sub Connector Plug, Male Pins 8 (Coax) Position Panel Mount, Through Hole Solder
- Datasheet Download
- DCMN8C8PNA191.pdf
Availability of DCMN8C8PNA191
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 87.90660
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of DCMN8C8PNA191, we specialize in ITT Cannon, LLC all series electronic components. DCMN8C8PNA191 can be shipped within 24 hours after order. If you have any demands for DCMN8C8PNA191, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- DCMN8C8PNA191 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
DCMN8C8PNA191
| Internal Part Number | EIS-DCMN8C8PNA191 | |
| Lead Free Status / RoHS Status | Vendor undefined / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Connectors, Interconnects | |
| Family | D-Sub Connectors | |
| Series | Combo D®, D*M | |
| Packaging | Bulk | |
| Connector Style | D-Sub, Combo | |
| Connector Type | Plug, Male Pins | |
| Number of Positions | 8 (Coax) | |
| Number of Rows | 1 | |
| Shell Size, Connector Layout | 4 (DC, C) - 8W8 | |
| Contact Type | Coax | |
| Mounting Type | Panel Mount, Through Hole | |
| Flange Feature | Mating Side; Female Screwlock (4-40) | |
| Termination | Solder | |
| Features | Board Lock, Shielded | |
| Shell Material, Finish | Steel, Yellow Chromate Plated Zinc | |
| Contact Finish | Gold | |
| Contact Finish Thickness | - | |
| Ingress Protection | - | |
| Operating Temperature | -55°C ~ 125°C | |
| Voltage Rating | - | |
| Current Rating | 5A | |
| Housing Material | Polyester | |
| Color | Black | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | DCMN8C8PNA191 | |
| Related Links | DCMN8C, DCMN8C8PNA191 Datasheet, ITT Cannon, LLC Distributor | |
DCMN8C8PNA191 Details Description
