Schurter DD12.2111.111
- Mfg. Part Number
- DD12.2111.111
- Manufacturer
- Schurter
- Product Category
- Power Entry Connectors - Inlets, Outlets, Modules
- Brief Description
- POWER ENTRY MOD W/FILTER 2A 1PL
- Datasheet Download
- DD12.2111.111.pdf
Availability of DD12.2111.111
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 17.49882
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of DD12.2111.111, we specialize in Schurter all series electronic components. DD12.2111.111 can be shipped within 24 hours after order. If you have any demands for DD12.2111.111, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- DD12.2111.111 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
DD12.2111.111
| Internal Part Number | EIS-DD12.2111.111 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | DD Series Power Entry Module | |
| 3D Model | DD12 Series.igsDD12 Series.stpDD12 Series.x_bDD12 Series.dxfDD12 Series.wrl | |
| PCN Design/Specification | DD12 Fusedrawer 04/Dec/2013 | |
| PCN Packaging | Multiple Devices 20/Nov/2015 | |
| Standard Package | 20 | |
| Category | Connectors, Interconnects | |
| Family | Power Entry Connectors - Inlets, Outlets, Modules | |
| Series | DD12 | |
| Packaging | Bulk | |
| Connector Style | IEC 320-C14 | |
| Connector Type | Receptacle, Male Blades - Module | |
| Current - IEC | 2A | |
| Voltage - IEC | 250VAC | |
| Current - UL | 2A | |
| Voltage - UL | 250VAC | |
| Filter Type | Filtered (EMI, RFI) - Commercial | |
| Fuse | Yes | |
| Number of Positions | 3 | |
| Mounting Type | Panel Mount, Flange | |
| Termination | Quick Connect - 0.250" (6.3mm) | |
| Switch Features | Switch On-Off | |
| Features | Shielded | |
| Fuse Holder, Drawer | Drawer Sold Separate | |
| Panel Cutout Dimensions | - | |
| Panel Thickness | - | |
| Material Flammability Rating | UL94 V-0 | |
| Ingress Protection | IP40 | |
| Approvals | cULus, ENEC | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | DD12.2111.111 | |
| Related Links | DD12.2, DD12.2111.111 Datasheet, Schurter Distributor | |
DD12.2111.111 Details Description
