ITT Cannon, LLC DDMAE78SNMB
- Mfg. Part Number
- DDMAE78SNMB
- Manufacturer
- ITT Cannon, LLC
- Product Category
- D-Sub Connectors
- Brief Description
- D-Sub Connector Receptacle, Female Sockets 78 Position Panel Mount Crimp
- Datasheet Download
- DDMAE78SNMB.pdf
Availability of DDMAE78SNMB
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 130.56080
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of DDMAE78SNMB, we specialize in ITT Cannon, LLC all series electronic components. DDMAE78SNMB can be shipped within 24 hours after order. If you have any demands for DDMAE78SNMB, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- DDMAE78SNMB Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
DDMAE78SNMB
| Internal Part Number | EIS-DDMAE78SNMB | |
| Lead Free Status / RoHS Status | Vendor undefined / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Connectors, Interconnects | |
| Family | D-Sub Connectors | |
| Series | MIL-DTL-24308, D*MA | |
| Packaging | Bulk | |
| Connector Style | D-Sub, High Density | |
| Connector Type | Receptacle, Female Sockets | |
| Number of Positions | 78 | |
| Number of Rows | 4 | |
| Shell Size, Connector Layout | 5 (DD, D) High Density | |
| Contact Type | Signal | |
| Mounting Type | Panel Mount | |
| Flange Feature | Board Side (4-40) | |
| Termination | Crimp | |
| Features | - | |
| Shell Material, Finish | Brass, Yellow Chromate Plated Cadmium | |
| Contact Finish | Gold | |
| Contact Finish Thickness | 50µin (1.27µm) | |
| Ingress Protection | - | |
| Operating Temperature | -55°C ~ 125°C | |
| Voltage Rating | - | |
| Current Rating | 7.5A | |
| Housing Material | Thermoplastic | |
| Color | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | DDMAE78SNMB | |
| Related Links | DDMAE, DDMAE78SNMB Datasheet, ITT Cannon, LLC Distributor | |
DDMAE78SNMB Details Description
