Hirose Electric Co Ltd DF11-8DP-2DSA(20)
- Mfg. Part Number
- DF11-8DP-2DSA(20)
- Manufacturer
- Hirose Electric Co Ltd
- Product Category
- Rectangular Connectors - Headers, Male Pins
- Brief Description
- CONN HEADER 8POS 2MM PCB TIN
- Datasheet Download
- DF11-8DP-2DSA(20).pdf
Availability of DF11-8DP-2DSA(20)
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of DF11-8DP-2DSA(20), we specialize in Hirose Electric Co Ltd all series electronic components. DF11-8DP-2DSA(20) can be shipped within 24 hours after order. If you have any demands for DF11-8DP-2DSA(20), Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- DF11-8DP-2DSA(20) Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
DF11-8DP-2DSA(20)
| Internal Part Number | EIS-DF11-8DP-2DSA(20) | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 49 | |
| Category | Connectors, Interconnects | |
| Family | Rectangular Connectors - Headers, Male Pins | |
| Series | DF11 | |
| Packaging | Tube | |
| Contact Type | Male Pin | |
| Connector Type | Header, Shrouded | |
| Number of Positions | 8 | |
| Number of Positions Loaded | All | |
| Pitch | 0.079" (2.00mm) | |
| Number of Rows | 2 | |
| Row Spacing | 0.079" (2.00mm) | |
| Contact Mating Length | 0.118" (3.00mm) | |
| Mounting Type | Through Hole | |
| Termination | Solder | |
| Fastening Type | Detent Lock | |
| Features | - | |
| Contact Finish | Tin | |
| Contact Finish Thickness | - | |
| Color | Black | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | DF11-8DP-2DSA(20) | |
| Related Links | DF11-8DP, DF11-8DP-2DSA(20) Datasheet, Hirose Electric Co Ltd Distributor | |
DF11-8DP-2DSA(20) Details Description
