Hirose Electric Co Ltd DF12D(3.0)-20DP-0.5V(81)
-20DP-0.jpg)
- Mfg. Part Number
- DF12D(3.0)-20DP-0.5V(81)
- Manufacturer
- Hirose Electric Co Ltd
- Product Category
- Rectangular - Board to Board Connectors - Arrays, Edge Type, Mezzanine
- Brief Description
- CONN HEADER 20POS 3MM SMD 0.5MM
- Datasheet Download
- DF12D(3.0)-20DP-0.5V(81).pdf
Availability of DF12D(3.0)-20DP-0.5V(81)
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.59800
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of DF12D(3.0)-20DP-0.5V(81), we specialize in Hirose Electric Co Ltd all series electronic components. DF12D(3.0)-20DP-0.5V(81) can be shipped within 24 hours after order. If you have any demands for DF12D(3.0)-20DP-0.5V(81), Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- DF12D(3.0)-20DP-0.5V(81) Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
DF12D(3.0)-20DP-0.5V(81)
| Internal Part Number | EIS-DF12D(3.0)-20DP-0.5V(81) | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Board to Board and Board to FPC Connectors | |
| Featured Product | DF12 Series | |
| Standard Package | 1,000 | |
| Category | Connectors, Interconnects | |
| Family | Rectangular - Board to Board Connectors - Arrays, Edge Type, Mezzanine | |
| Series | DF12 | |
| Packaging | Tape & Reel (TR) | |
| Connector Type | Header, Outer Shroud Contacts | |
| Number of Positions | 20 | |
| Pitch | 0.020" (0.50mm) | |
| Number of Rows | 2 | |
| Mounting Type | Surface Mount | |
| Features | Board Guide | |
| Contact Finish | Gold | |
| Contact Finish Thickness | - | |
| Mated Stacking Heights | 3mm | |
| Height Above Board | 0.091" (2.30mm) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | DF12D(3.0)-20DP-0.5V(81) | |
| Related Links | DF12D(3.0)-2, DF12D(3.0)-20DP-0.5V(81) Datasheet, Hirose Electric Co Ltd Distributor | |
