Hirose Electric Co Ltd DF17(4.0)-30DS-0.5V(57)
30DS0.5V(51.jpg)
- Mfg. Part Number
- DF17(4.0)-30DS-0.5V(57)
- Manufacturer
- Hirose Electric Co Ltd
- Product Category
- Rectangular - Board to Board Connectors - Arrays, Edge Type, Mezzanine
- Brief Description
- CONN RECEPT 30POS .5MM SMD W/FIT
- Datasheet Download
- DF17(4.0)-30DS-0.5V(57).pdf
Availability of DF17(4.0)-30DS-0.5V(57)
Available Quantity
12020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.81900
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of DF17(4.0)-30DS-0.5V(57), we specialize in Hirose Electric Co Ltd all series electronic components. DF17(4.0)-30DS-0.5V(57) can be shipped within 24 hours after order. If you have any demands for DF17(4.0)-30DS-0.5V(57), Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- DF17(4.0)-30DS-0.5V(57) Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
DF17(4.0)-30DS-0.5V(57)
| Internal Part Number | EIS-DF17(4.0)-30DS-0.5V(57) | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Board to Board and Board to FPC Connectors | |
| Standard Package | 1,000 | |
| Category | Connectors, Interconnects | |
| Family | Rectangular - Board to Board Connectors - Arrays, Edge Type, Mezzanine | |
| Series | DF17 | |
| Packaging | Tape & Reel (TR) | |
| Connector Type | Receptacle, Center Strip Contacts | |
| Number of Positions | 30 | |
| Pitch | 0.020" (0.50mm) | |
| Number of Rows | 2 | |
| Mounting Type | Surface Mount | |
| Features | Board Guide, Solder Retention | |
| Contact Finish | Gold | |
| Contact Finish Thickness | - | |
| Mated Stacking Heights | 6mm, 6.5mm, 8mm | |
| Height Above Board | 0.177" (4.50mm) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | DF17(4.0)-30DS-0.5V(57) | |
| Related Links | DF17(4.0)-3, DF17(4.0)-30DS-0.5V(57) Datasheet, Hirose Electric Co Ltd Distributor | |
