Hirose Electric Co Ltd DF7-3P-3.96DSA
- Mfg. Part Number
- DF7-3P-3.96DSA
- Manufacturer
- Hirose Electric Co Ltd
- Product Category
- Rectangular Connectors - Headers, Male Pins
- Brief Description
- CONN HEADER 3POS 3.96MM VERT TIN
- Datasheet Download
- DF7-3P-3.96DSA.pdf
Availability of DF7-3P-3.96DSA
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of DF7-3P-3.96DSA, we specialize in Hirose Electric Co Ltd all series electronic components. DF7-3P-3.96DSA can be shipped within 24 hours after order. If you have any demands for DF7-3P-3.96DSA, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- DF7-3P-3.96DSA Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
DF7-3P-3.96DSA
| Internal Part Number | EIS-DF7-3P-3.96DSA | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 100 | |
| Category | Connectors, Interconnects | |
| Family | Rectangular Connectors - Headers, Male Pins | |
| Series | DF7 | |
| Packaging | Bulk | |
| Contact Type | Male Pin | |
| Connector Type | Header, Shrouded | |
| Number of Positions | 3 | |
| Number of Positions Loaded | All | |
| Pitch | 0.156" (3.96mm) | |
| Number of Rows | 1 | |
| Row Spacing | - | |
| Contact Mating Length | 0.276" (7.00mm) | |
| Mounting Type | Through Hole | |
| Termination | Solder | |
| Fastening Type | Latch Holder | |
| Features | Board Guide | |
| Contact Finish | Tin | |
| Contact Finish Thickness | - | |
| Color | Beige | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | DF7-3P-3.96DSA | |
| Related Links | DF7-3P-, DF7-3P-3.96DSA Datasheet, Hirose Electric Co Ltd Distributor | |
