Cherry DG23-B1LA
- Mfg. Part Number
- DG23-B1LA
- Manufacturer
- Cherry
- Product Category
- Snap Action, Limit Switches
- Brief Description
- SWITCH LEVER SPDT 50MA PC 30V
- Datasheet Download
- DG23-B1LA.pdf
Availability of DG23-B1LA
Available Quantity
5916 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.26000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of DG23-B1LA, we specialize in Cherry all series electronic components. DG23-B1LA can be shipped within 24 hours after order. If you have any demands for DG23-B1LA, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- DG23-B1LA Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
DG23-B1LA
| Internal Part Number | EIS-DG23-B1LA | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1,000 | |
| Category | Switches | |
| Family | Snap Action, Limit Switches | |
| Series | DG | |
| Packaging | Bulk | |
| Circuit | SPDT | |
| Switch Function | On-Mom | |
| Current Rating | 50mA (DC) | |
| Voltage Rating - AC | - | |
| Voltage Rating - DC | 30V | |
| Actuator Type | Lever, Straight | |
| Mounting Type | Through Hole | |
| Termination Style | PC Pin | |
| Ingress Protection | IP40 | |
| Features | - | |
| Operating Force, Torque | 45gf | |
| Release Force | - | |
| Pretravel | 0.071" (1.8mm) | |
| Differential Travel | 0.020" (0.5mm) | |
| Overtravel | 0.022" (0.55mm) | |
| Operating Position | 0.268" (6.8mm) | |
| Mechanical Life | 1,000,000 Cycles | |
| Electrical Life | 200,000 Cycles | |
| Operating Temperature | -25°C ~ 85°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | DG23-B1LA | |
| Related Links | DG23, DG23-B1LA Datasheet, Cherry Distributor | |
