3M DIN-096CSC-PSL-HM
- Mfg. Part Number
- DIN-096CSC-PSL-HM
- Manufacturer
- 3M
- Product Category
- Backplane Connectors - DIN 41612
- Brief Description
- CONN DIN SOCKET 96POS VERT GOLD
- Datasheet Download
- DIN-096CSC-PSL-HM.pdf
Availability of DIN-096CSC-PSL-HM
Available Quantity
5551 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 4.84400
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of DIN-096CSC-PSL-HM, we specialize in 3M all series electronic components. DIN-096CSC-PSL-HM can be shipped within 24 hours after order. If you have any demands for DIN-096CSC-PSL-HM, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- DIN-096CSC-PSL-HM Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
DIN-096CSC-PSL-HM
| Internal Part Number | EIS-DIN-096CSC-PSL-HM | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 756 | |
| Category | Connectors, Interconnects | |
| Family | Backplane Connectors - DIN 41612 | |
| Series | DIN 41612 | |
| Packaging | Bulk | |
| Connector Type | Receptacle, Female Sockets | |
| Number of Positions | 96 | |
| Number of Positions Loaded | All | |
| Pitch | 0.100" (2.54mm) | |
| Number of Rows | 3 | |
| Style | C | |
| Level, Class | - | |
| Mounting Type | Through Hole | |
| Termination | Press-Fit | |
| Features | - | |
| Contact Finish | Gold | |
| Contact Finish Thickness | 3µin (0.08µm) | |
| Operating Temperature | -55°C ~ 125°C | |
| Current Rating | 3A | |
| Material Flammability Rating | UL94 V-0 | |
| Material - Insulation | Polybutylene Terephthalate (PBT), Polyester, Glass Filled | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | DIN-096CSC-PSL-HM | |
| Related Links | DIN-096C, DIN-096CSC-PSL-HM Datasheet, 3M Distributor | |
