TE Connectivity Deutsch Connectors DL60R10-02PY-6117
- Mfg. Part Number
- DL60R10-02PY-6117
- Manufacturer
- TE Connectivity Deutsch Connectors
- Product Category
- Circular Connectors
- Brief Description
- CONN RCPT 2POS FLANGE W/PINS
- Datasheet Download
- DL60R10-02PY-6117.pdf
Availability of DL60R10-02PY-6117
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 40.70170
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of DL60R10-02PY-6117, we specialize in TE Connectivity Deutsch Connectors all series electronic components. DL60R10-02PY-6117 can be shipped within 24 hours after order. If you have any demands for DL60R10-02PY-6117, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- DL60R10-02PY-6117 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
DL60R10-02PY-6117
| Internal Part Number | EIS-DL60R10-02PY-6117 | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Connectors, Interconnects | |
| Family | Circular Connectors | |
| Series | MIL-C-83723 Series III | |
| Packaging | Bulk | |
| Connector Type | Receptacle, Male Pins | |
| Number of Positions | 2 | |
| Shell Size - Insert | 10-2 | |
| Shell Size, MIL | - | |
| Mounting Type | Panel Mount, Flange | |
| Termination | Crimp | |
| Fastening Type | Bayonet Lock | |
| Orientation | Y | |
| Ingress Protection | IP67 - Dust Tight, Waterproof | |
| Shell Material, Finish | Aluminum, Olive Drab Cadmium Plated | |
| Contact Finish | Gold | |
| Features | - | |
| Contact Finish Thickness | 50µin (1.27µm) | |
| Current Rating | 7.5A | |
| Voltage - Rated | - | |
| Operating Temperature | -55°C ~ 200°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | DL60R10-02PY-6117 | |
| Related Links | DL60R10-, DL60R10-02PY-6117 Datasheet, TE Connectivity Deutsch Connectors Distributor | |
DL60R10-02PY-6117 Details Description
