Apem Inc. DM10
- Mfg. Part Number
- DM10
- Manufacturer
- Apem Inc.
- Product Category
- DIP Switches
- Brief Description
- LOW PROFILE DIP SWITCH
- Datasheet Download
- DM10.pdf
Availability of DM10
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 2.07833
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of DM10, we specialize in Apem Inc. all series electronic components. DM10 can be shipped within 24 hours after order. If you have any demands for DM10, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- DM10 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
DM10
| Internal Part Number | EIS-DM10 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 18 | |
| Category | Switches | |
| Family | DIP Switches | |
| Series | DM | |
| Packaging | Tube | |
| Circuit | SPST | |
| Number of Positions | 10 | |
| Current Rating | 25mA | |
| Voltage Rating | 24VDC | |
| Actuator Type | Slide (Standard) | |
| Actuator Level | Raised | |
| Contact Material | Copper Alloy | |
| Contact Finish | Gold | |
| Height Above Board | 0.173" (4.40mm) | |
| Mounting Type | Surface Mount | |
| Termination Style | Gull Wing | |
| Pitch | 0.100" (2.54mm), Full | |
| Washable | No | |
| Features | - | |
| Body Material | Polyphenylene Sulfide (PPS), Glass Filled | |
| Length | 1.037" (26.34mm) | |
| Operating Temperature | -20°C ~ 85°C | |
| Mechanical Life | 2,000 Cycles | |
| Electrical Life | 2,000 Cycles | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | DM10 | |
| Related Links | DM, DM10 Datasheet, Apem Inc. Distributor | |
