Fairchild Semiconductor DM7406M
- Mfg. Part Number
- DM7406M
- Manufacturer
- Fairchild Semiconductor
- Product Category
- Logic - Gates and Inverters
- Brief Description
- IC INVERTER HEX OPEN OUT 14-SOIC
- Datasheet Download
- DM7406M.pdf
Availability of DM7406M
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of DM7406M, we specialize in Fairchild Semiconductor all series electronic components. DM7406M can be shipped within 24 hours after order. If you have any demands for DM7406M, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- DM7406M Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
DM7406M
| Internal Part Number | EIS-DM7406M | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 55 | |
| Category | Integrated Circuits (ICs) | |
| Family | Logic - Gates and Inverters | |
| Series | 7400 | |
| Packaging | Tube | |
| Logic Type | Inverter | |
| Number of Circuits | 6 | |
| Number of Inputs | 6 | |
| Features | Open Collector | |
| Voltage - Supply | 4.75 V ~ 5.25 V | |
| Current - Quiescent (Max) | - | |
| Current - Output High, Low | -, 40mA | |
| Logic Level - Low | 0.8V | |
| Logic Level - High | 2V | |
| Max Propagation Delay @ V, Max CL | 23ns @ 5V, 15pF | |
| Operating Temperature | 0°C ~ 70°C | |
| Mounting Type | Surface Mount | |
| Supplier Device Package | 14-SOIC | |
| Package / Case | 14-SOIC (0.154", 3.90mm Width) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | DM7406M | |
| Related Links | DM7, DM7406M Datasheet, Fairchild Semiconductor Distributor | |
DM7406M Details Description
