Diodes Incorporated DMN3008SFG-13
- Mfg. Part Number
- DMN3008SFG-13
- Manufacturer
- Diodes Incorporated
- Product Category
- FETs - Single
- Brief Description
- MOSFET N-CH 30V 17.6A POWERDI
- Datasheet Download
- DMN3008SFG-13.pdf
Availability of DMN3008SFG-13
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.24360
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of DMN3008SFG-13, we specialize in Diodes Incorporated all series electronic components. DMN3008SFG-13 can be shipped within 24 hours after order. If you have any demands for DMN3008SFG-13, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- DMN3008SFG-13 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
DMN3008SFG-13
| Internal Part Number | EIS-DMN3008SFG-13 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 3,000 | |
| Category | Discrete Semiconductor Products | |
| Family | FETs - Single | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| FET Type | MOSFET N-Channel, Metal Oxide | |
| FET Feature | Standard | |
| Drain to Source Voltage (Vdss) | 30V | |
| Current - Continuous Drain (Id) @ 25°C | 17.6A (Ta) | |
| Rds On (Max) @ Id, Vgs | 4.6 mOhm @ 13.5A, 10V | |
| Vgs(th) (Max) @ Id | 2.3V @ 250µA | |
| Gate Charge (Qg) @ Vgs | 86nC @ 10V | |
| Input Capacitance (Ciss) @ Vds | 3690pF @ 10V | |
| Power - Max | 900mW | |
| Mounting Type | Surface Mount | |
| Package / Case | 8-PowerWDFN | |
| Supplier Device Package | PowerDI3333-8 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | DMN3008SFG-13 | |
| Related Links | DMN300, DMN3008SFG-13 Datasheet, Diodes Incorporated Distributor | |
DMN3008SFG-13 Details Description
