JAE Electronics DP1RD20JQ2
- Mfg. Part Number
- DP1RD20JQ2
- Manufacturer
- JAE Electronics
- Product Category
- USB, DVI, HDMI Connectors
- Brief Description
- CONN RCPT 20POS R/A TOP MT GOLD
- Datasheet Download
- DP1RD20JQ2.pdf
Availability of DP1RD20JQ2
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 2.72000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of DP1RD20JQ2, we specialize in JAE Electronics all series electronic components. DP1RD20JQ2 can be shipped within 24 hours after order. If you have any demands for DP1RD20JQ2, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- DP1RD20JQ2 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
DP1RD20JQ2
| Internal Part Number | EIS-DP1RD20JQ2 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 184 | |
| Category | Connectors, Interconnects | |
| Family | USB, DVI, HDMI Connectors | |
| Series | DP1 | |
| Packaging | Bulk | |
| Connector Type | DisplayPort | |
| Number of Contacts | 20 | |
| Gender | Receptacle | |
| Specifications | Display Port 1.1a | |
| Mounting Type | Surface Mount, Right Angle, Horizontal | |
| Features | Board Guide | |
| Ingress Protection | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | DP1RD20JQ2 | |
| Related Links | DP1RD, DP1RD20JQ2 Datasheet, JAE Electronics Distributor | |
