Pulse Electronics Corporation DP241-7-120A50
- Mfg. Part Number
- DP241-7-120A50
- Manufacturer
- Pulse Electronics Corporation
- Product Category
- Power Transformers
- Brief Description
- XFRMR LAMINATED 56VA CHAS MOUNT
- Datasheet Download
- DP241-7-120A50.pdf
Availability of DP241-7-120A50
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 12.85000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of DP241-7-120A50, we specialize in Pulse Electronics Corporation all series electronic components. DP241-7-120A50 can be shipped within 24 hours after order. If you have any demands for DP241-7-120A50, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- DP241-7-120A50 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
DP241-7-120A50
| Internal Part Number | EIS-DP241-7-120A50 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 24 | |
| Category | Transformers | |
| Family | Power Transformers | |
| Series | Chassis-Tran | |
| Type | Laminated Core | |
| Voltage - Primary | 115V, 230V | |
| Voltage - Secondary (Full Load) | 120V | |
| Current - Output (Max) | 500mA | |
| Primary Winding(s) | Dual | |
| Secondary Winding(s) | Single | |
| Center Tap | Yes | |
| Power - Max | 56 VA | |
| Mounting Type | Chassis Mount | |
| Termination Style | Solder, Quick Connect | |
| Size / Dimension | 93.73mm L x 57.15mm W | |
| Height - Seated (Max) | 45.97mm | |
| Voltage - Isolation | 2500Vrms | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | DP241-7-120A50 | |
| Related Links | DP241-7, DP241-7-120A50 Datasheet, Pulse Electronics Corporation Distributor | |
DP241-7-120A50 Details Description
