E-Switch DR4A-16R-B
- Mfg. Part Number
- DR4A-16R-B
- Manufacturer
- E-Switch
- Product Category
- DIP Switches
- Brief Description
- SWITCH ROTARY DIP
- Datasheet Download
- DR4A-16R-B.pdf
Availability of DR4A-16R-B
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.43220
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of DR4A-16R-B, we specialize in E-Switch all series electronic components. DR4A-16R-B can be shipped within 24 hours after order. If you have any demands for DR4A-16R-B, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- DR4A-16R-B Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
DR4A-16R-B
| Internal Part Number | EIS-DR4A-16R-B | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 48 | |
| Category | Switches | |
| Family | DIP Switches | |
| Series | DR | |
| Packaging | Tube | |
| Circuit | Hexadecimal | |
| Number of Positions | 16 | |
| Current Rating | 25mA | |
| Voltage Rating | 24VDC | |
| Actuator Type | Rotary for Tool | |
| Actuator Level | Flush, Recessed | |
| Contact Material | Copper | |
| Contact Finish | Gold | |
| Height Above Board | 0.389" (9.90mm) | |
| Mounting Type | Through Hole, Right Angle | |
| Termination Style | PC Pin | |
| Pitch | 0.100" (2.54mm), Full | |
| Washable | No | |
| Features | - | |
| Body Material | Polyamide (PA), Nylon | |
| Length | 0.386" (9.80mm) | |
| Operating Temperature | -25°C ~ 80°C | |
| Mechanical Life | - | |
| Electrical Life | 15,000 Cycles | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | DR4A-16R-B | |
| Related Links | DR4A-, DR4A-16R-B Datasheet, E-Switch Distributor | |
DR4A-16R-B Details Description
