Eaton (formerly Cooper Bussmann) DR74-471-R
- Mfg. Part Number
- DR74-471-R
- Manufacturer
- Eaton (formerly Cooper Bussmann)
- Product Category
- Fixed Inductors
- Brief Description
- FIXED IND 470UH 400MA 1.74 OHM
- Datasheet Download
- DR74-471-R.pdf
Availability of DR74-471-R
Available Quantity
28120 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.66500
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of DR74-471-R, we specialize in Eaton (formerly Cooper Bussmann) all series electronic components. DR74-471-R can be shipped within 24 hours after order. If you have any demands for DR74-471-R, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- DR74-471-R Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
DR74-471-R
| Internal Part Number | EIS-DR74-471-R | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Shielded Drum Core Inductor Coiltronics DR Series | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 1,100 | |
| Category | Inductors, Coils, Chokes | |
| Family | Fixed Inductors | |
| Series | DR | |
| Packaging | Tape & Reel (TR) | |
| Type | Wirewound | |
| Material - Core | Ferrite | |
| Inductance | 470µH | |
| Tolerance | ±20% | |
| Current Rating | 400mA | |
| Current - Saturation | 460mA | |
| Shielding | Shielded | |
| DC Resistance (DCR) | 1.74 Ohm | |
| Q @ Freq | - | |
| Frequency - Self Resonant | - | |
| Operating Temperature | -40°C ~ 125°C | |
| Frequency - Test | 100kHz | |
| Mounting Type | Surface Mount | |
| Package / Case | Nonstandard | |
| Size / Dimension | 0.299" L x 0.299" W (7.60mm x 7.60mm) | |
| Height - Seated (Max) | 0.171" (4.35mm) | |
| Supplier Device Package | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | DR74-471-R | |
| Related Links | DR74-, DR74-471-R Datasheet, Eaton (formerly Cooper Bussmann) Distributor | |
DR74-471-R Details Description
