TE Connectivity Alcoswitch Switches DRD10RAE
- Mfg. Part Number
- DRD10RAE
- Manufacturer
- TE Connectivity Alcoswitch Switches
- Product Category
- DIP Switches
- Brief Description
- SWITCH DIP FLUSH 10POS THRU HOLE
- Datasheet Download
- DRD10RAE.pdf
Availability of DRD10RAE
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of DRD10RAE, we specialize in TE Connectivity Alcoswitch Switches all series electronic components. DRD10RAE can be shipped within 24 hours after order. If you have any demands for DRD10RAE, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- DRD10RAE Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
DRD10RAE
| Internal Part Number | EIS-DRD10RAE | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| RoHS Information | DRD10RAE Statement of Compliance | |
| Standard Package | 35 | |
| Category | Switches | |
| Family | DIP Switches | |
| Series | DRD | |
| Packaging | Tube | |
| Circuit | BCD | |
| Number of Positions | 10 | |
| Current Rating | 0.4VA | |
| Voltage Rating | 20VAC/DC | |
| Actuator Type | Rotary for Tool | |
| Actuator Level | Flush, Recessed | |
| Contact Material | Copper Alloy | |
| Contact Finish | Gold | |
| Height Above Board | 0.413" (10.50mm) | |
| Mounting Type | Through Hole, Right Angle | |
| Termination Style | PC Pin | |
| Pitch | 0.100" (2.54mm), Full | |
| Washable | Yes | |
| Features | - | |
| Body Material | Polyphenylene Sulfide (PPS) | |
| Length | 0.393" (10.00mm) | |
| Operating Temperature | -30°C ~ 85°C | |
| Mechanical Life | 20,000 Steps | |
| Electrical Life | 20,000 Steps | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | DRD10RAE | |
| Related Links | DRD1, DRD10RAE Datasheet, TE Connectivity Alcoswitch Switches Distributor | |
DRD10RAE Details Description
