Texas Instruments DRV8802PWP
- Mfg. Part Number
- DRV8802PWP
- Manufacturer
- Texas Instruments
- Product Category
- PMIC - Motor Drivers, Controllers
- Brief Description
- IC MOTOR DRIVER PAR 28HTSSOP
- Datasheet Download
- DRV8802PWP.pdf
Availability of DRV8802PWP
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.95750
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of DRV8802PWP, we specialize in Texas Instruments all series electronic components. DRV8802PWP can be shipped within 24 hours after order. If you have any demands for DRV8802PWP, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- DRV8802PWP Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
DRV8802PWP
| Internal Part Number | EIS-DRV8802PWP | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 2,000 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Motor Drivers, Controllers | |
| Series | - | |
| Motor Type - Stepper | - | |
| Motor Type - AC, DC | Brushed DC | |
| Function | Driver - Fully Integrated, Control and Power Stage | |
| Output Configuration | Half Bridge (4) | |
| Interface | Parallel | |
| Technology | Power MOSFET | |
| Step Resolution | - | |
| Applications | General Purpose | |
| Current - Output | 1.1A | |
| Voltage - Supply | 8.2 V ~ 45 V | |
| Voltage - Load | 8.2 V ~ 45 V | |
| Operating Temperature | -40°C ~ 150°C (TJ) | |
| Mounting Type | Surface Mount | |
| Package / Case | 28-TSSOP (0.173", 4.40mm Width) Exposed Pad | |
| Supplier Device Package | 28-HTSSOP | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | DRV8802PWP | |
| Related Links | DRV88, DRV8802PWP Datasheet, Texas Instruments Distributor | |
