Texas Instruments DRV8805DWR
- Mfg. Part Number
- DRV8805DWR
- Manufacturer
- Texas Instruments
- Product Category
- PMIC - Motor Drivers, Controllers
- Brief Description
- IC MOTOR DRIVER PAR 20SOIC
- Datasheet Download
- DRV8805DWR.pdf
Availability of DRV8805DWR
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.68750
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of DRV8805DWR, we specialize in Texas Instruments all series electronic components. DRV8805DWR can be shipped within 24 hours after order. If you have any demands for DRV8805DWR, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- DRV8805DWR Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
DRV8805DWR
| Internal Part Number | EIS-DRV8805DWR | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 2 (1 Year) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 2,000 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Motor Drivers, Controllers | |
| Series | - | |
| Motor Type - Stepper | Unipolar | |
| Motor Type - AC, DC | Brushed DC | |
| Function | Driver - Fully Integrated, Control and Power Stage | |
| Output Configuration | Low Side (4) | |
| Interface | Step/Direction | |
| Technology | Power MOSFET | |
| Step Resolution | 1, 1/2 | |
| Applications | General Purpose | |
| Current - Output | 800mA | |
| Voltage - Supply | 8.2 V ~ 60 V | |
| Voltage - Load | 8.2 V ~ 60 V | |
| Operating Temperature | -40°C ~ 150°C (TJ) | |
| Mounting Type | Surface Mount | |
| Package / Case | 20-SOIC (0.295", 7.50mm Width) | |
| Supplier Device Package | 20-SOIC | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | DRV8805DWR | |
| Related Links | DRV88, DRV8805DWR Datasheet, Texas Instruments Distributor | |
