Maxim Integrated DS3992Z-18P+
- Mfg. Part Number
- DS3992Z-18P+
- Manufacturer
- Maxim Integrated
- Product Category
- PMIC - Lighting, Ballast Controllers
- Brief Description
- IC CTRLR CCFL 180-440HZ 16-SOIC
- Datasheet Download
- DS3992Z-18P+.pdf
Availability of DS3992Z-18P+
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of DS3992Z-18P+, we specialize in Maxim Integrated all series electronic components. DS3992Z-18P+ can be shipped within 24 hours after order. If you have any demands for DS3992Z-18P+, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- DS3992Z-18P+ Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
DS3992Z-18P+
| Internal Part Number | EIS-DS3992Z-18P+ | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Mfg Application Notes | CCFL Push-Pull Snubber Circuit Implementing Analog Dimming on the DS39xx CCFL Controllers Enhancing the Gate-Drive Capacity of the DS39xx CCFL Controllers Determining LCM and OVD Thresholds for the DS3xxx CCFL Controllers | |
| Product Training Modules | Lead (SnPb) Finish for COTS Long-Term Supply Program | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 1 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Lighting, Ballast Controllers | |
| Series | - | |
| Packaging | Tube | |
| Type | CCFL Controller | |
| Frequency | 40kHz ~ 80kHz | |
| Voltage - Supply | 4.5 V ~ 5.5 V | |
| Current - Supply | 8mA | |
| Current - Output Source/Sink | - | |
| Dimming | Yes | |
| Operating Temperature | -40°C ~ 85°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 16-SOIC (0.154", 3.90mm Width) | |
| Drawing Number | 175; 21-0041; SE; 16 | |
| Mfr Reel Diameter | - | |
| Mfr Reel Tape Material | - | |
| Mfr Reel Tape Width | - | |
| Supplier Device Package | 16-SOIC | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | DS3992Z-18P+ | |
| Related Links | DS3992, DS3992Z-18P+ Datasheet, Maxim Integrated Distributor | |
