Murata Electronics North America DSN6NB31H271Q91A
- Mfg. Part Number
- DSN6NB31H271Q91A
- Manufacturer
- Murata Electronics North America
- Product Category
- EMI/RFI Filters (LC, RC Networks)
- Brief Description
- FILTER EMI 270PF 50V RADIAL
- Datasheet Download
- DSN6NB31H271Q91A.pdf
Availability of DSN6NB31H271Q91A
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.17696
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of DSN6NB31H271Q91A, we specialize in Murata Electronics North America all series electronic components. DSN6NB31H271Q91A can be shipped within 24 hours after order. If you have any demands for DSN6NB31H271Q91A, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- DSN6NB31H271Q91A Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
DSN6NB31H271Q91A
| Internal Part Number | EIS-DSN6NB31H271Q91A | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 2,000 | |
| Category | Filters | |
| Family | EMI/RFI Filters (LC, RC Networks) | |
| Series | EMIFIL®, DSN6N | |
| Packaging | Tape & Box (TB) | |
| Type | Low Pass | |
| Technology | LC (T-Type) | |
| Number of Channels | 1 | |
| Center / Cutoff Frequency | - | |
| Attenuation Value | - | |
| Resistance - Channel (Ohms) | - | |
| Current | 6A | |
| Values | C = 270pF | |
| ESD Protection | No | |
| Filter Order | 2nd | |
| Applications | General Purpose | |
| Package / Case | Radial - 3 Leads | |
| Size / Dimension | 0.276" L x 1.000" W (7.00mm x 2.54mm) | |
| Height | 0.315" (8.00mm) | |
| Operating Temperature | -25°C ~ 85°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | DSN6NB31H271Q91A | |
| Related Links | DSN6NB31, DSN6NB31H271Q91A Datasheet, Murata Electronics North America Distributor | |
DSN6NB31H271Q91A Details Description
