Panasonic Electric Works DSP1-L2-DC3V
- Mfg. Part Number
- DSP1-L2-DC3V
- Manufacturer
- Panasonic Electric Works
- Product Category
- Power Relays, Over 2 Amps
- Brief Description
- RELAY GENERAL PURPOSE DPST 5A 3V
- Datasheet Download
- DSP1-L2-DC3V.pdf
Availability of DSP1-L2-DC3V
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of DSP1-L2-DC3V, we specialize in Panasonic Electric Works all series electronic components. DSP1-L2-DC3V can be shipped within 24 hours after order. If you have any demands for DSP1-L2-DC3V, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- DSP1-L2-DC3V Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
DSP1-L2-DC3V
| Internal Part Number | EIS-DSP1-L2-DC3V | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Other Related Documents | Standards Chart How to Read Date Codes | |
| Standard Package | 50 | |
| Category | Relays | |
| Family | Power Relays, Over 2 Amps | |
| Series | DSP | |
| Packaging | Bulk | |
| Relay Type | General Purpose | |
| Coil Type | Latching, Dual Coil | |
| Coil Current | 100mA | |
| Coil Voltage | 3VDC | |
| Contact Form | DPST-NO/NC (1 Form A and B) | |
| Contact Rating (Current) | 5A | |
| Switching Voltage | 250VAC, 30VDC - Max | |
| Turn On Voltage (Max) | 2.4 VDC | |
| Turn Off Voltage (Min) | - | |
| Operate Time | 10ms | |
| Release Time | 5ms | |
| Features | Sealed - Fully | |
| Mounting Type | Through Hole | |
| Termination Style | PC Pin | |
| Contact Material | Silver Tin Oxide (AgSnO) | |
| Coil Power | 300 mW | |
| Coil Resistance | 30 Ohms | |
| Operating Temperature | -40°C ~ 65°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | DSP1-L2-DC3V | |
| Related Links | DSP1-L, DSP1-L2-DC3V Datasheet, Panasonic Electric Works Distributor | |
DSP1-L2-DC3V Details Description
