Microchip Technology DSPIC30F1010T-30I/SO
- Mfg. Part Number
- DSPIC30F1010T-30I/SO
- Manufacturer
- Microchip Technology
- Product Category
- Embedded - Microcontrollers
- Brief Description
- IC DSC 16BIT 6KB FLASH 28SOIC
- Datasheet Download
- DSPIC30F1010T-30I/SO.pdf
Availability of DSPIC30F1010T-30I/SO
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of DSPIC30F1010T-30I/SO, we specialize in Microchip Technology all series electronic components. DSPIC30F1010T-30I/SO can be shipped within 24 hours after order. If you have any demands for DSPIC30F1010T-30I/SO, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- DSPIC30F1010T-30I/SO Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
DSPIC30F1010T-30I/SO
| Internal Part Number | EIS-DSPIC30F1010T-30I/SO | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Design Resources | Development Tool Selector | |
| PCN Design/Specification | dsPIC30F1010/202x Datasheet Update 19/Mar/2014 | |
| PCN Packaging | Label and Packing Changes 23/Sep/2015 | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 1,600 | |
| Category | Integrated Circuits (ICs) | |
| Family | Embedded - Microcontrollers | |
| Series | dsPIC™ 30F | |
| Packaging | Tape & Reel (TR) | |
| Core Processor | dsPIC | |
| Core Size | 16-Bit | |
| Speed | 30 MIPs | |
| Connectivity | I²C, IrDA, LIN, SPI, UART/USART | |
| Peripherals | Brown-out Detect/Reset, POR, PWM, WDT | |
| Number of I/O | 21 | |
| Program Memory Size | 6KB (2K x 24) | |
| Program Memory Type | FLASH | |
| EEPROM Size | - | |
| RAM Size | 256 x 8 | |
| Voltage - Supply (Vcc/Vdd) | 3 V ~ 5.5 V | |
| Data Converters | A/D 6x10b | |
| Oscillator Type | Internal | |
| Operating Temperature | -40°C ~ 85°C | |
| Package / Case | 28-SOIC (0.295", 7.50mm Width) | |
| Supplier Device Package | 28-SOIC | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | DSPIC30F1010T-30I/SO | |
| Related Links | DSPIC30F10, DSPIC30F1010T-30I/SO Datasheet, Microchip Technology Distributor | |
DSPIC30F1010T-30I/SO Details Description
