Hirose Electric Co Ltd DX10G1M-26S
- Mfg. Part Number
- DX10G1M-26S
- Manufacturer
- Hirose Electric Co Ltd
- Product Category
- D-Shaped Connectors - Centronics
- Brief Description
- CONN RECEPT RT ANG 26POS PCB
- Datasheet Download
- DX10G1M-26S.pdf
Availability of DX10G1M-26S
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of DX10G1M-26S, we specialize in Hirose Electric Co Ltd all series electronic components. DX10G1M-26S can be shipped within 24 hours after order. If you have any demands for DX10G1M-26S, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- DX10G1M-26S Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
DX10G1M-26S
| Internal Part Number | EIS-DX10G1M-26S | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 60 | |
| Category | Connectors, Interconnects | |
| Family | D-Shaped Connectors - Centronics | |
| Series | DXM | |
| Connector Style | Outer Shroud Contacts | |
| Connector Type | Receptacle | |
| Number of Positions | 26 | |
| Number of Rows | 2 | |
| Mounting Type | Panel Mount, Through Hole, Right Angle | |
| Termination | Solder | |
| Flange Feature | Insert, Threaded (M2.6); Latchblocks | |
| Type | Miniature High Density (HD) | |
| Features | - | |
| Contact Finish | Gold | |
| Contact Finish Thickness | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | DX10G1M-26S | |
| Related Links | DX10G, DX10G1M-26S Datasheet, Hirose Electric Co Ltd Distributor | |
DX10G1M-26S Details Description
