Omron Automation & Safety E5CZ-Q2MLD AC/DC24
- Mfg. Part Number
- E5CZ-Q2MLD AC/DC24
- Manufacturer
- Omron Automation & Safety
- Product Category
- Controllers - Process, Temperature
- Brief Description
- CONTROL PROCESS REL/VOLT OUT 24V
- Datasheet Download
- E5CZ-Q2MLD AC/DC24.pdf
Availability of E5CZ-Q2MLD AC/DC24
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 343.65000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of E5CZ-Q2MLD AC/DC24, we specialize in Omron Automation & Safety all series electronic components. E5CZ-Q2MLD AC/DC24 can be shipped within 24 hours after order. If you have any demands for E5CZ-Q2MLD AC/DC24, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- E5CZ-Q2MLD AC/DC24 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
E5CZ-Q2MLD AC/DC24
| Internal Part Number | EIS-E5CZ-Q2MLD AC/DC24 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| PCN Design/Specification | Multiple devices Modification July/2013 | |
| Standard Package | 1 | |
| Category | Industrial Controls, Meters | |
| Family | Controllers - Process, Temperature | |
| Series | E5CZ | |
| Type | Process Controller | |
| Input Range | 0 ~ 20mA, 0 ~ 10VDC | |
| Output Type | Relay (2), Voltage (External SSR) | |
| Control Method | On/Off, Proportional (PID) | |
| Communications | Option Cards Available | |
| Number Of Characters Per Row | 4, 4 | |
| Display Type | LCD - Dual Color Characters, Backlight | |
| Display Characters - Height | 0.433" (11.00mm), 0.256" (6.50mm) | |
| Voltage - Supply | 24VAC/DC | |
| Panel Cutout Dimensions | Square - 45.00mm x 45.00mm | |
| Mounting Type | Panel Mount | |
| Termination Style | Screw Terminal | |
| Ingress Protection | IP66 (Face), IP20 (Case), IP00 (Terminal) | |
| Operating Temperature | -10°C ~ 55°C | |
| Features | Option Cards Available | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | E5CZ-Q2MLD AC/DC24 | |
| Related Links | E5CZ-Q2ML, E5CZ-Q2MLD AC/DC24 Datasheet, Omron Automation & Safety Distributor | |
