Everlight Electronics Co Ltd EALP03SXDOA1-AM
- Mfg. Part Number
- EALP03SXDOA1-AM
- Manufacturer
- Everlight Electronics Co Ltd
- Product Category
- LED Indication - Discrete
- Brief Description
- LED ORANGE CLEAR 4DIP THRU HOLE
- Datasheet Download
- EALP03SXDOA1-AM.pdf
Availability of EALP03SXDOA1-AM
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.40000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of EALP03SXDOA1-AM, we specialize in Everlight Electronics Co Ltd all series electronic components. EALP03SXDOA1-AM can be shipped within 24 hours after order. If you have any demands for EALP03SXDOA1-AM, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- EALP03SXDOA1-AM Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
EALP03SXDOA1-AM
| Internal Part Number | EIS-EALP03SXDOA1-AM | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 80 | |
| Category | Optoelectronics | |
| Family | LED Indication - Discrete | |
| Series | - | |
| Packaging | Bulk | |
| Color | Orange | |
| Lens Color | Colorless | |
| Lens Transparency | Clear | |
| Millicandela Rating | - | |
| Lens Style/Size | Round with Domed Top, 3.00mm | |
| Voltage - Forward (Vf) (Typ) | 2.4V | |
| Current - Test | 70mA | |
| Viewing Angle | 50° | |
| Mounting Type | Through Hole | |
| Wavelength - Dominant | 616nm | |
| Wavelength - Peak | 621nm | |
| Features | - | |
| Package / Case | 4-DIP (0.200", 5.08mm) | |
| Supplier Device Package | P-LED | |
| Size / Dimension | - | |
| Height (Max) | 6.10mm | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | EALP03SXDOA1-AM | |
| Related Links | EALP03S, EALP03SXDOA1-AM Datasheet, Everlight Electronics Co Ltd Distributor | |
EALP03SXDOA1-AM Details Description
