Sullins Connector Solutions EBC36MMJD
- Mfg. Part Number
- EBC36MMJD
- Manufacturer
- Sullins Connector Solutions
- Product Category
- Card Edge Connectors - Edgeboard Connectors
- Brief Description
- CARDEDGE MALE .100 72POS R/A AU
- Datasheet Download
- EBC36MMJD.pdf
Availability of EBC36MMJD
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 8.19600
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of EBC36MMJD, we specialize in Sullins Connector Solutions all series electronic components. EBC36MMJD can be shipped within 24 hours after order. If you have any demands for EBC36MMJD, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- EBC36MMJD Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
EBC36MMJD
| Internal Part Number | EIS-EBC36MMJD | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Connectors, Interconnects | |
| Family | Card Edge Connectors - Edgeboard Connectors | |
| Series | - | |
| Packaging | Tray | |
| Card Type | Fits Female Edgecards | |
| Gender | Male | |
| Number of Positions/Bay/Row | 36 | |
| Number of Positions | 72 | |
| Card Thickness | 0.062" (1.57mm) | |
| Number of Rows | 2 | |
| Pitch | 0.100" (2.54mm) | |
| Features | - | |
| Mounting Type | Through Hole, Right Angle | |
| Termination | Solder | |
| Contact Material | Phosphor Bronze | |
| Contact Finish | Gold | |
| Contact Finish Thickness | 10µin (0.25µm) | |
| Contact Type | - | |
| Color | Blue | |
| Flange Feature | Flush Mount, Top Opening, Unthreaded, 0.125" (3.18mm) Dia | |
| Operating Temperature | -65°C ~ 125°C | |
| Material - Insulation | Polybutylene Terephthalate (PBT) | |
| Read Out | Dual | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | EBC36MMJD | |
| Related Links | EBC3, EBC36MMJD Datasheet, Sullins Connector Solutions Distributor | |
