XP Power ECE40US48-S
- Mfg. Part Number
- ECE40US48-S
- Manufacturer
- XP Power
- Product Category
- AC DC Converters
- Brief Description
- AC/DC CONVERTER 48V 40W
- Datasheet Download
- ECE40US48-S.pdf
Availability of ECE40US48-S
Available Quantity
5054 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 53.81994
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of ECE40US48-S, we specialize in XP Power all series electronic components. ECE40US48-S can be shipped within 24 hours after order. If you have any demands for ECE40US48-S, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- ECE40US48-S Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
ECE40US48-S
| Internal Part Number | EIS-ECE40US48-S | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Other Related Documents | ECE(20 - 40) Series TUV Certificate ECE(20 - 40) Series UL Certificate ECE(20 - 40) Series CB Report | |
| Video File | ECE 5 to 60 Watts Encapsulated PCB & Chassis | |
| RoHS Information | ECE(20 - 40) Series Declaration of Conformity | |
| Standard Package | 1 | |
| Category | Power Supplies - External/Internal (Off-Board) | |
| Family | AC DC Converters | |
| Series | ECE | |
| Type | Enclosed | |
| Number of Outputs | 1 | |
| Voltage - Input | 85 ~ 264 VAC | |
| Voltage - Output 1 | 48V | |
| Voltage - Output 2 | - | |
| Voltage - Output 3 | - | |
| Voltage - Output 4 | - | |
| Current - Output (Max) | 830mA | |
| Power (Watts) | 40W | |
| Applications | ITE (Commercial) | |
| Voltage - Isolation | 3kV (3000V) | |
| Efficiency | 86% | |
| Operating Temperature | -25°C ~ 70°C | |
| Features | DC Input Capable, Universal Input | |
| Mounting Type | Chassis Mount | |
| Size / Dimension | 3.78" L x 1.57" W x 1.12" H (96.0mm x 40.0mm x 28.5mm) | |
| Minimum Load Required | No | |
| Approvals | - | |
| Power (Watts) - Max | 40W | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | ECE40US48-S | |
| Related Links | ECE40, ECE40US48-S Datasheet, XP Power Distributor | |
