Panasonic Electronic Components ECH-S1224JZ
- Mfg. Part Number
- ECH-S1224JZ
- Manufacturer
- Panasonic Electronic Components
- Product Category
- Film Capacitors
- Brief Description
- CAP FILM 0.22UF 5% 100VDC RADIAL
- Datasheet Download
- ECH-S1224JZ.pdf
Availability of ECH-S1224JZ
Available Quantity
5270 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.68712
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of ECH-S1224JZ, we specialize in Panasonic Electronic Components all series electronic components. ECH-S1224JZ can be shipped within 24 hours after order. If you have any demands for ECH-S1224JZ, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- ECH-S1224JZ Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
ECH-S1224JZ
| Internal Part Number | EIS-ECH-S1224JZ | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| PCN Obsolescence/ EOL | ECQ-(B,P,M,F,K),ECH-S 18/June/2008 | |
| Standard Package | 100 | |
| Category | Capacitors | |
| Family | Film Capacitors | |
| Series | ECHS | |
| Packaging | Bulk | |
| Capacitance | 0.22µF | |
| Tolerance | ±5% | |
| Voltage Rating - AC | - | |
| Voltage Rating - DC | 100V | |
| Dielectric Material | Polyphenylene Sulfide (PPS) | |
| ESR (Equivalent Series Resistance) | - | |
| Operating Temperature | -40°C ~ 125°C | |
| Mounting Type | Through Hole | |
| Package / Case | Radial | |
| Size / Dimension | 0.807" L x 0.335" W (20.50mm x 8.50mm) | |
| Height - Seated (Max) | 0.677" (17.20mm) | |
| Termination | PC Pins | |
| Lead Spacing | 0.591" (15.00mm) | |
| Applications | General Purpose | |
| Features | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | ECH-S1224JZ | |
| Related Links | ECH-S, ECH-S1224JZ Datasheet, Panasonic Electronic Components Distributor | |
