Panasonic Electronic Components ECW-FD2W684KB
- Mfg. Part Number
- ECW-FD2W684KB
- Manufacturer
- Panasonic Electronic Components
- Product Category
- Film Capacitors
- Brief Description
- CAP FILM 0.68UF 10% 450VDC RAD
- Datasheet Download
- ECW-FD2W684KB.pdf
Availability of ECW-FD2W684KB
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.19992
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of ECW-FD2W684KB, we specialize in Panasonic Electronic Components all series electronic components. ECW-FD2W684KB can be shipped within 24 hours after order. If you have any demands for ECW-FD2W684KB, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- ECW-FD2W684KB Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
ECW-FD2W684KB
| Internal Part Number | EIS-ECW-FD2W684KB | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Video File | Fuse Function for Film Capacitors | |
| Standard Package | 1,000 | |
| Category | Capacitors | |
| Family | Film Capacitors | |
| Series | ECW-F(D) | |
| Packaging | Bulk | |
| Capacitance | 0.68µF | |
| Tolerance | ±10% | |
| Voltage Rating - AC | - | |
| Voltage Rating - DC | 450V | |
| Dielectric Material | Polypropylene (PP), Metallized | |
| ESR (Equivalent Series Resistance) | - | |
| Operating Temperature | -40°C ~ 110°C | |
| Mounting Type | Through Hole | |
| Package / Case | Radial | |
| Size / Dimension | 0.689" L x 0.264" W (17.50mm x 6.70mm) | |
| Height - Seated (Max) | 0.587" (14.90mm) | |
| Termination | PC Pins | |
| Lead Spacing | 0.295" (7.50mm) | |
| Applications | High Frequency, Switching | |
| Features | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | ECW-FD2W684KB | |
| Related Links | ECW-FD, ECW-FD2W684KB Datasheet, Panasonic Electronic Components Distributor | |
