On-Shore Technology, Inc. EDSTL955/9
- Mfg. Part Number
- EDSTL955/9
- Manufacturer
- On-Shore Technology, Inc.
- Product Category
- Terminal Blocks - Headers, Plugs and Sockets
- Brief Description
- TERM BLOCK HDR 9POS VERT 5MM
- Datasheet Download
- EDSTL955/9.pdf
Availability of EDSTL955/9
Available Quantity
5516 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.09760
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of EDSTL955/9, we specialize in On-Shore Technology, Inc. all series electronic components. EDSTL955/9 can be shipped within 24 hours after order. If you have any demands for EDSTL955/9, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- EDSTL955/9 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
EDSTL955/9
| Internal Part Number | EIS-EDSTL955/9 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Other Related Documents | ED Part Number Breakdown | |
| Standard Package | 50 | |
| Category | Connectors, Interconnects | |
| Family | Terminal Blocks - Headers, Plugs and Sockets | |
| Series | EDSTL955 | |
| Packaging | Bulk | |
| Type | Header, Male Pins, Shrouded (4 Side) | |
| Number of Positions | 9 | |
| Positions Per Level | 9 | |
| Number of Levels | 1 | |
| Pitch | 0.197" (5.00mm) | |
| Header Orientation | Vertical | |
| Plug Wire Entry | - | |
| Termination Style | Solder | |
| Mounting Type | Through Hole | |
| Current - IEC | - | |
| Voltage - IEC | - | |
| Current - UL | 15A | |
| Voltage - UL | 300V | |
| Wire Gauge or Range - AWG | - | |
| Wire Gauge or Range - mm² | - | |
| Color | Green | |
| Operating Temperature | -30°C ~ 105°C | |
| Contact Mating Finish | - | |
| Features | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | EDSTL955/9 | |
| Related Links | EDSTL, EDSTL955/9 Datasheet, On-Shore Technology, Inc. Distributor | |
