Panasonic Electronic Components EEF-CS1C330R
- Mfg. Part Number
- EEF-CS1C330R
- Manufacturer
- Panasonic Electronic Components
- Product Category
- Aluminum - Polymer Capacitors
- Brief Description
- CAP POLYMER 33UF 20% 16V SMD
- Datasheet Download
- EEF-CS1C330R.pdf
Availability of EEF-CS1C330R
Available Quantity
8520 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.57396
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of EEF-CS1C330R, we specialize in Panasonic Electronic Components all series electronic components. EEF-CS1C330R can be shipped within 24 hours after order. If you have any demands for EEF-CS1C330R, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- EEF-CS1C330R Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
EEF-CS1C330R
| Internal Part Number | EIS-EEF-CS1C330R | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 3,500 | |
| Category | Capacitors | |
| Family | Aluminum - Polymer Capacitors | |
| Series | SP-Cap CS | |
| Packaging | Tape & Reel (TR) | |
| Capacitance | 33µF | |
| Tolerance | ±20% | |
| Voltage Rating | 16V | |
| ESR (Equivalent Series Resistance) | 40 mOhm | |
| Lifetime @ Temp. | 1000 Hrs @ 105°C | |
| Operating Temperature | -40°C ~ 105°C | |
| Type | Polymer | |
| Applications | General Purpose | |
| Ripple Current | 3A | |
| Impedance | - | |
| Lead Spacing | - | |
| Size / Dimension | 0.287" L x 0.169" W (7.30mm x 4.30mm) | |
| Height - Seated (Max) | 0.047" (1.20mm) | |
| Surface Mount Land Size | - | |
| Mounting Type | Surface Mount | |
| Package / Case | 2917 (7343 Metric) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | EEF-CS1C330R | |
| Related Links | EEF-CS, EEF-CS1C330R Datasheet, Panasonic Electronic Components Distributor | |
EEF-CS1C330R Details Description
