Sanken EG 1A
- Mfg. Part Number
- EG 1A
- Manufacturer
- Sanken
- Product Category
- Diodes, Rectifiers - Single
- Brief Description
- DIODE GEN PURP 600V 600MA AXIAL
- Datasheet Download
- EG 1A.pdf
Availability of EG 1A
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.17400
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of EG 1A, we specialize in Sanken all series electronic components. EG 1A can be shipped within 24 hours after order. If you have any demands for EG 1A, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- EG 1A Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
EG 1A
| Internal Part Number | EIS-EG 1A | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1,000 | |
| Category | Discrete Semiconductor Products | |
| Family | Diodes, Rectifiers - Single | |
| Series | - | |
| Packaging | Bulk | |
| Diode Type | Standard | |
| Voltage - DC Reverse (Vr) (Max) | 600V | |
| Current - Average Rectified (Io) | 600mA | |
| Voltage - Forward (Vf) (Max) @ If | 2V @ 600mA | |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) | |
| Reverse Recovery Time (trr) | 100ns | |
| Current - Reverse Leakage @ Vr | 100µA @ 600V | |
| Capacitance @ Vr, F | - | |
| Mounting Type | Through Hole | |
| Package / Case | Axial | |
| Supplier Device Package | - | |
| Operating Temperature - Junction | -40°C ~ 150°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | EG 1A | |
| Related Links | EG, EG 1A Datasheet, Sanken Distributor | |
EG 1A Details Description
