United Chemi-Con EKZN160ELL681MH15D
- Mfg. Part Number
- EKZN160ELL681MH15D
- Manufacturer
- United Chemi-Con
- Product Category
- Aluminum Capacitors
- Brief Description
- CAP ALUM 680UF 20% 16V RADIAL
- Datasheet Download
- EKZN160ELL681MH15D.pdf
Availability of EKZN160ELL681MH15D
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.13996
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of EKZN160ELL681MH15D, we specialize in United Chemi-Con all series electronic components. EKZN160ELL681MH15D can be shipped within 24 hours after order. If you have any demands for EKZN160ELL681MH15D, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- EKZN160ELL681MH15D Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
EKZN160ELL681MH15D
| Internal Part Number | EIS-EKZN160ELL681MH15D | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Featured Product | KZN Series Aluminum Electrolytic Capacitors | |
| Standard Package | 1,000 | |
| Category | Capacitors | |
| Family | Aluminum Capacitors | |
| Series | KZN | |
| Packaging | Bulk | |
| Capacitance | 680µF | |
| Tolerance | ±20% | |
| Voltage Rating | 16V | |
| ESR (Equivalent Series Resistance) | - | |
| Lifetime @ Temp. | 10000 Hrs @ 105°C | |
| Operating Temperature | - | |
| Type | - | |
| Applications | General Purpose | |
| Ripple Current | 1.6A | |
| Impedance | 59 mOhm | |
| Lead Spacing | 0.138" (3.50mm) | |
| Size / Dimension | 0.315" Dia (8.00mm) | |
| Height - Seated (Max) | 0.650" (16.50mm) | |
| Surface Mount Land Size | - | |
| Mounting Type | Through Hole | |
| Package / Case | Radial, Can | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | EKZN160ELL681MH15D | |
| Related Links | EKZN160EL, EKZN160ELL681MH15D Datasheet, United Chemi-Con Distributor | |
