Everlight Electronics Co Ltd EL3H7(TB)-VG
- Mfg. Part Number
- EL3H7(TB)-VG
- Manufacturer
- Everlight Electronics Co Ltd
- Product Category
- Optoisolators - Transistor, Photovoltaic Output
- Brief Description
- OPTOISOLATOR 3.75KV TRANS 4-SSOP
- Datasheet Download
- EL3H7(TB)-VG.pdf
Availability of EL3H7(TB)-VG
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.12096
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of EL3H7(TB)-VG, we specialize in Everlight Electronics Co Ltd all series electronic components. EL3H7(TB)-VG can be shipped within 24 hours after order. If you have any demands for EL3H7(TB)-VG, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- EL3H7(TB)-VG Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
EL3H7(TB)-VG
| Internal Part Number | EIS-EL3H7(TB)-VG | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 5,000 | |
| Category | Isolators | |
| Family | Optoisolators - Transistor, Photovoltaic Output | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Number of Channels | 1 | |
| Voltage - Isolation | 3750Vrms | |
| Current Transfer Ratio (Min) | 50% @ 5mA | |
| Current Transfer Ratio (Max) | 600% @ 5mA | |
| Turn On / Turn Off Time (Typ) | - | |
| Rise / Fall Time (Typ) | 5µs, 3µs | |
| Input Type | DC | |
| Output Type | Transistor | |
| Voltage - Output (Max) | 80V | |
| Current - Output / Channel | 50mA | |
| Voltage - Forward (Vf) (Typ) | 1.2V | |
| Current - DC Forward (If) (Max) | 50mA | |
| Vce Saturation (Max) | 200mV | |
| Operating Temperature | -55°C ~ 110°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 4-SOIC (0.173", 4.40mm) | |
| Supplier Device Package | 4-SSOP | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | EL3H7(TB)-VG | |
| Related Links | EL3H7(, EL3H7(TB)-VG Datasheet, Everlight Electronics Co Ltd Distributor | |
