Intersil EL7242CS-T7
- Mfg. Part Number
- EL7242CS-T7
- Manufacturer
- Intersil
- Product Category
- PMIC - Gate Drivers
- Brief Description
- IC DRIVER MOSFET DUAL HS 8-SOIC
- Datasheet Download
- EL7242CS-T7.pdf
Availability of EL7242CS-T7
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of EL7242CS-T7, we specialize in Intersil all series electronic components. EL7242CS-T7 can be shipped within 24 hours after order. If you have any demands for EL7242CS-T7, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- EL7242CS-T7 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
EL7242CS-T7
| Internal Part Number | EIS-EL7242CS-T7 | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1,000 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Gate Drivers | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Configuration | High and Low Side, Synchronous | |
| Input Type | Differential | |
| Delay Time | 20ns | |
| Current - Peak | 2A | |
| Number of Configurations | 1 | |
| Number of Outputs | 2 | |
| High Side Voltage - Max (Bootstrap) | - | |
| Voltage - Supply | 4.5 V ~ 16 V | |
| Operating Temperature | -40°C ~ 85°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) | |
| Supplier Device Package | 8-SOIC | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | EL7242CS-T7 | |
| Related Links | EL724, EL7242CS-T7 Datasheet, Intersil Distributor | |
EL7242CS-T7 Details Description
