Panasonic Electronic Components ELC-08D4R7E
- Mfg. Part Number
- ELC-08D4R7E
- Manufacturer
- Panasonic Electronic Components
- Product Category
- Fixed Inductors
- Brief Description
- FIXED IND 4.7UH 4.3A 15 MOHM TH
- Datasheet Download
- ELC-08D4R7E.pdf
Availability of ELC-08D4R7E
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.28014
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of ELC-08D4R7E, we specialize in Panasonic Electronic Components all series electronic components. ELC-08D4R7E can be shipped within 24 hours after order. If you have any demands for ELC-08D4R7E, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- ELC-08D4R7E Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
ELC-08D4R7E
| Internal Part Number | EIS-ELC-08D4R7E | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 1,000 | |
| Category | Inductors, Coils, Chokes | |
| Family | Fixed Inductors | |
| Series | 08D | |
| Packaging | Bulk | |
| Type | - | |
| Material - Core | Ferrite | |
| Inductance | 4.7µH | |
| Tolerance | ±20% | |
| Current Rating | 4.3A | |
| Current - Saturation | - | |
| Shielding | Unshielded | |
| DC Resistance (DCR) | 15 mOhm | |
| Q @ Freq | - | |
| Frequency - Self Resonant | - | |
| Operating Temperature | - | |
| Frequency - Test | 10kHz | |
| Mounting Type | Through Hole | |
| Package / Case | Radial | |
| Size / Dimension | 0.394" Dia x 0.512" H (10.00mm x 13.00mm) | |
| Height - Seated (Max) | * | |
| Supplier Device Package | * | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | ELC-08D4R7E | |
| Related Links | ELC-0, ELC-08D4R7E Datasheet, Panasonic Electronic Components Distributor | |
ELC-08D4R7E Details Description
