Everlight Electronics Co Ltd ELSW-E71B1-0LPNM-CB7B8
- Mfg. Part Number
- ELSW-E71B1-0LPNM-CB7B8
- Manufacturer
- Everlight Electronics Co Ltd
- Product Category
- LED Lighting - Color
- Brief Description
- LED SHWO 1W HI PWR BLUESMD
- Datasheet Download
- ELSW-E71B1-0LPNM-CB7B8.pdf
Availability of ELSW-E71B1-0LPNM-CB7B8
Available Quantity
5420 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.20000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of ELSW-E71B1-0LPNM-CB7B8, we specialize in Everlight Electronics Co Ltd all series electronic components. ELSW-E71B1-0LPNM-CB7B8 can be shipped within 24 hours after order. If you have any demands for ELSW-E71B1-0LPNM-CB7B8, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- ELSW-E71B1-0LPNM-CB7B8 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
ELSW-E71B1-0LPNM-CB7B8
| Internal Part Number | EIS-ELSW-E71B1-0LPNM-CB7B8 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Design Resources | Lighting Product Selector | |
| Standard Package | 400 | |
| Category | Optoelectronics | |
| Family | LED Lighting - Color | |
| Series | SHWO | |
| Packaging | Tape & Reel (TR) | |
| Color | Blue | |
| Wavelength | 465nm (460nm ~ 470nm) | |
| Flux @ 25°C, Current - Test | 17 lm (17 lm ~ 20 lm) | |
| Current - Test | 350mA | |
| Voltage - Forward (Vf) (Typ) | 3.25V (2.65 V ~ 4.15 V) | |
| Current - Max | 600mA | |
| Viewing Angle | 120° | |
| Mounting Type | Surface Mount | |
| Package / Case | 2-SMD, No Lead, Exposed Pad | |
| Lumens/Watt @ Current - Test | 15 lm/W | |
| Flux @ 85°C, Current - Test | 15 lm | |
| Thermal Resistance of Package | 10°C/W | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | ELSW-E71B1-0LPNM-CB7B8 | |
| Related Links | ELSW-E71B1-, ELSW-E71B1-0LPNM-CB7B8 Datasheet, Everlight Electronics Co Ltd Distributor | |
ELSW-E71B1-0LPNM-CB7B8 Details Description
