Alt EPM7256BTC144-5
- Mfg. Part Number
- EPM7256BTC144-5
- Manufacturer
- Alt
- Product Category
- Embedded - CPLDs (Complex Programmable Logic Devices)
- Brief Description
- IC CPLD 256MC 5NS 144TQFP
- Datasheet Download
- EPM7256BTC144-5.pdf
Availability of EPM7256BTC144-5
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 138.00000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of EPM7256BTC144-5, we specialize in Alt all series electronic components. EPM7256BTC144-5 can be shipped within 24 hours after order. If you have any demands for EPM7256BTC144-5, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- EPM7256BTC144-5 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
EPM7256BTC144-5
| Internal Part Number | EIS-EPM7256BTC144-5 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| PCN Design/Specification | Appearance Update 30/Mar/2015 | |
| Standard Package | 60 | |
| Category | Integrated Circuits (ICs) | |
| Family | Embedded - CPLDs (Complex Programmable Logic Devices) | |
| Series | MAX® 7000B | |
| Packaging | Tray | |
| Programmable Type | In System Programmable | |
| Delay Time tpd(1) Max | 5.0ns | |
| Voltage Supply - Internal | 2.375 V ~ 2.625 V | |
| Number of Logic Elements/Blocks | 16 | |
| Number of Macrocells | 256 | |
| Number of Gates | 5000 | |
| Number of I/O | 120 | |
| Operating Temperature | 0°C ~ 70°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 144-LQFP | |
| Supplier Device Package | 144-TQFP (20x20) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | EPM7256BTC144-5 | |
| Related Links | EPM7256, EPM7256BTC144-5 Datasheet, Alt Distributor | |
EPM7256BTC144-5 Details Description
