Panasonic Electronic Components ERJ-L1WKJ10CU
- Mfg. Part Number
- ERJ-L1WKJ10CU
- Manufacturer
- Panasonic Electronic Components
- Product Category
- Chip Resistor - Surface Mount
- Brief Description
- RES SMD 0.1 OHM 5% 1W 2512
- Datasheet Download
- ERJ-L1WKJ10CU.pdf
Availability of ERJ-L1WKJ10CU
Available Quantity
35020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.23160
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of ERJ-L1WKJ10CU, we specialize in Panasonic Electronic Components all series electronic components. ERJ-L1WKJ10CU can be shipped within 24 hours after order. If you have any demands for ERJ-L1WKJ10CU, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- ERJ-L1WKJ10CU Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
ERJ-L1WKJ10CU
| Internal Part Number | EIS-ERJ-L1WKJ10CU | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Automotive Resistor Products LED Lighting Components | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 3,000 | |
| Category | Resistors | |
| Family | Chip Resistor - Surface Mount | |
| Series | ERJ | |
| Packaging | Tape & Reel (TR) | |
| Resistance (Ohms) | 0.1 | |
| Tolerance | ±5% | |
| Power (Watts) | 1W | |
| Composition | Thick Film | |
| Features | Automotive AEC-Q200, Current Sense | |
| Temperature Coefficient | ±100ppm/°C | |
| Operating Temperature | -55°C ~ 125°C | |
| Package / Case | 2512 (6432 Metric) | |
| Supplier Device Package | 2512 | |
| Size / Dimension | 0.252" L x 0.126" W (6.40mm x 3.20mm) | |
| Height | 0.047" (1.20mm) | |
| Number of Terminations | 2 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | ERJ-L1WKJ10CU | |
| Related Links | ERJ-L1, ERJ-L1WKJ10CU Datasheet, Panasonic Electronic Components Distributor | |
ERJ-L1WKJ10CU Details Description
