ON Semiconductor ESDR0544MDMR4G
- Mfg. Part Number
- ESDR0544MDMR4G
- Manufacturer
- ON Semiconductor
- Product Category
- TVS - Diodes
- Brief Description
- TVS DIODE 5VWM MICRO10
- Datasheet Download
- ESDR0544MDMR4G.pdf
Availability of ESDR0544MDMR4G
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of ESDR0544MDMR4G, we specialize in ON Semiconductor all series electronic components. ESDR0544MDMR4G can be shipped within 24 hours after order. If you have any demands for ESDR0544MDMR4G, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- ESDR0544MDMR4G Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
ESDR0544MDMR4G
| Internal Part Number | EIS-ESDR0544MDMR4G | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| PCN Obsolescence/ EOL | Multiple Devices 04/Jan/2013 | |
| Standard Package | 1,000 | |
| Category | Circuit Protection | |
| Family | TVS - Diodes | |
| Series | Automotive, AEC-Q101 | |
| Packaging | Tape & Reel (TR) | |
| Type | Steering (Rail to Rail) | |
| Unidirectional Channels | - | |
| Bidirectional Channels | 4 | |
| Voltage - Reverse Standoff (Typ) | 5V (Max) | |
| Voltage - Breakdown (Min) | 6V | |
| Voltage - Clamping (Max) @ Ipp | - | |
| Current - Peak Pulse (10/1000µs) | - | |
| Power - Peak Pulse | - | |
| Power Line Protection | Yes | |
| Applications | Automotive | |
| Capacitance @ Frequency | 0.7pF @ 1MHz | |
| Operating Temperature | -55°C ~ 125°C (TJ) | |
| Mounting Type | Surface Mount | |
| Package / Case | 10-TFSOP, 10-MSOP (0.118", 3.00mm Width) | |
| Supplier Device Package | 10-Micro | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | ESDR0544MDMR4G | |
| Related Links | ESDR054, ESDR0544MDMR4G Datasheet, ON Semiconductor Distributor | |
ESDR0544MDMR4G Details Description
