Panasonic Electronic Components EVJ-C25F02D14
- Mfg. Part Number
- EVJ-C25F02D14
- Manufacturer
- Panasonic Electronic Components
- Product Category
- Rotary Potentiometers, Rheostats
- Brief Description
- POT 10K OHM 1/20W LOGARITHMIC
- Datasheet Download
- EVJ-C25F02D14.pdf
Availability of EVJ-C25F02D14
Available Quantity
5511 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.84480
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of EVJ-C25F02D14, we specialize in Panasonic Electronic Components all series electronic components. EVJ-C25F02D14 can be shipped within 24 hours after order. If you have any demands for EVJ-C25F02D14, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- EVJ-C25F02D14 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
EVJ-C25F02D14
| Internal Part Number | EIS-EVJ-C25F02D14 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| PCN Obsolescence/ EOL | EFJ-Y EFJ-C Series Disc Notice 09/Oct/2014 | |
| Standard Package | 600 | |
| Category | Potentiometers, Variable Resistors | |
| Family | Rotary Potentiometers, Rheostats | |
| Series | EVJ | |
| Packaging | Bulk | |
| Taper | Logarithmic | |
| Resistance (Ohms) | 10k | |
| Tolerance | ±20% | |
| Number of Gangs | 2 | |
| Built in Switch | None | |
| Power (Watts) | 0.05W, 1/20W | |
| Temperature Coefficient | - | |
| Number of Turns | 1 | |
| Rotation | 300° | |
| Adjustment Type | Side Adjustment | |
| Resistive Material | - | |
| Termination Style | PCB Pins, Board Locks | |
| Actuator Type | Flatted | |
| Actuator Length | 0.689" (17.50mm) | |
| Actuator Diameter | 0.236" (6.00mm) | |
| Bushing Thread | - | |
| Mounting Type | Through Hole, Snap In | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | EVJ-C25F02D14 | |
| Related Links | EVJ-C2, EVJ-C25F02D14 Datasheet, Panasonic Electronic Components Distributor | |
EVJ-C25F02D14 Details Description
