Panasonic Electronic Components EVM-EASA00B16
- Mfg. Part Number
- EVM-EASA00B16
- Manufacturer
- Panasonic Electronic Components
- Product Category
- Trimmer Potentiometers
- Brief Description
- TRIMMER 1M OHM 0.3W TH
- Datasheet Download
- EVM-EASA00B16.pdf
Availability of EVM-EASA00B16
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of EVM-EASA00B16, we specialize in Panasonic Electronic Components all series electronic components. EVM-EASA00B16 can be shipped within 24 hours after order. If you have any demands for EVM-EASA00B16, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- EVM-EASA00B16 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
EVM-EASA00B16
| Internal Part Number | EIS-EVM-EASA00B16 | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| PCN Obsolescence/ EOL | EVM-EA(G,S) Type 17/Mar/2010 | |
| Category | Potentiometers, Variable Resistors | |
| Family | Trimmer Potentiometers | |
| Series | EVM-EAS | |
| Packaging | Tape & Box (TB) | |
| Resistance (Ohms) | 1M | |
| Power (Watts) | 0.3W | |
| Tolerance | ±25% | |
| Temperature Coefficient | ±200ppm/°C | |
| Number of Turns | Single | |
| Adjustment Type | Top Adjustment | |
| Resistive Material | Cermet | |
| Mounting Type | Through Hole | |
| Termination Style | PC Pin | |
| Size / Dimension | Rectangular - 0.315" x 0.252" Face x 0.299" H (8.00mm x 6.40mm x 7.60mm) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | EVM-EASA00B16 | |
| Related Links | EVM-EA, EVM-EASA00B16 Datasheet, Panasonic Electronic Components Distributor | |
EVM-EASA00B16 Details Description
