Sullins Connector Solutions EYM24DRMD
- Mfg. Part Number
- EYM24DRMD
- Manufacturer
- Sullins Connector Solutions
- Product Category
- Card Edge Connectors - Edgeboard Connectors
- Brief Description
- CONN EDGECARD 48POS .156 WW
- Datasheet Download
- EYM24DRMD.pdf
Availability of EYM24DRMD
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 7.62200
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of EYM24DRMD, we specialize in Sullins Connector Solutions all series electronic components. EYM24DRMD can be shipped within 24 hours after order. If you have any demands for EYM24DRMD, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- EYM24DRMD Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
EYM24DRMD
| Internal Part Number | EIS-EYM24DRMD | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Connectors, Interconnects | |
| Family | Card Edge Connectors - Edgeboard Connectors | |
| Series | - | |
| Packaging | Tray | |
| Card Type | Non Specified - Dual Edge | |
| Gender | Female | |
| Number of Positions/Bay/Row | 24 | |
| Number of Positions | 48 | |
| Card Thickness | 0.062" (1.57mm) | |
| Number of Rows | 2 | |
| Pitch | 0.156" (3.96mm) | |
| Features | - | |
| Mounting Type | Through Hole | |
| Termination | Wire Wrap | |
| Contact Material | Phosphor Bronze | |
| Contact Finish | Gold | |
| Contact Finish Thickness | 30µin (0.76µm) | |
| Contact Type | Loop Bellows | |
| Color | Blue | |
| Flange Feature | Flush Mount, Top Opening, Unthreaded, 0.125" (3.18mm) Dia | |
| Operating Temperature | -65°C ~ 125°C | |
| Material - Insulation | Polybutylene Terephthalate (PBT) | |
| Read Out | Dual | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | EYM24DRMD | |
| Related Links | EYM2, EYM24DRMD Datasheet, Sullins Connector Solutions Distributor | |
EYM24DRMD Details Description
