Amphenol RF FA1-NISJ-C09-0
- Mfg. Part Number
- FA1-NISJ-C09-0
- Manufacturer
- Amphenol RF
- Product Category
- Coaxial Connectors (RF)
- Brief Description
- CONN FAKRA JACK STR 50 OHM CRIMP
- Datasheet Download
- FA1-NISJ-C09-0.pdf
Availability of FA1-NISJ-C09-0
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.65200
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of FA1-NISJ-C09-0, we specialize in Amphenol RF all series electronic components. FA1-NISJ-C09-0 can be shipped within 24 hours after order. If you have any demands for FA1-NISJ-C09-0, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- FA1-NISJ-C09-0 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
FA1-NISJ-C09-0
| Internal Part Number | EIS-FA1-NISJ-C09-0 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | FAKRA Series | |
| Standard Package | 2,000 | |
| Category | Connectors, Interconnects | |
| Family | Coaxial Connectors (RF) | |
| Series | - | |
| Packaging | Bulk | |
| Connector Style | SMB, Fakra | |
| Connector Type | Jack, Female Socket | |
| Contact Termination | Crimp | |
| Shield Termination | Crimp | |
| Impedance | 50 Ohm | |
| Mounting Type | Free Hanging (In-Line) | |
| Cable Group | .057" OD | |
| Fastening Type | Locking Ramp | |
| Frequency - Max | 4GHz | |
| Features | Code I | |
| Housing Color | Beige | |
| Ingress Protection | - | |
| Body Material | Brass | |
| Body Finish | Nickel | |
| Center Contact Material | - | |
| Center Contact Plating | Gold | |
| Dielectric Material | - | |
| Voltage Rating | - | |
| Operating Temperature | -40°C ~ 100°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | FA1-NISJ-C09-0 | |
| Related Links | FA1-NIS, FA1-NISJ-C09-0 Datasheet, Amphenol RF Distributor | |
FA1-NISJ-C09-0 Details Description
