Fairchild Semiconductor FDMS3610S
- Mfg. Part Number
- FDMS3610S
- Manufacturer
- Fairchild Semiconductor
- Product Category
- FETs - Arrays
- Brief Description
- MOSFET 2N-CH 25V 17.5A/30A 8-MLP
- Datasheet Download
- FDMS3610S.pdf
Availability of FDMS3610S
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.78960
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of FDMS3610S, we specialize in Fairchild Semiconductor all series electronic components. FDMS3610S can be shipped within 24 hours after order. If you have any demands for FDMS3610S, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- FDMS3610S Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
FDMS3610S
| Internal Part Number | EIS-FDMS3610S | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 3,000 | |
| Category | Discrete Semiconductor Products | |
| Family | FETs - Arrays | |
| Series | PowerTrench® | |
| Packaging | Tape & Reel (TR) | |
| FET Type | 2 N-Channel (Dual) Asymmetrical | |
| FET Feature | Logic Level Gate | |
| Drain to Source Voltage (Vdss) | 25V | |
| Current - Continuous Drain (Id) @ 25°C | 17.5A, 30A | |
| Rds On (Max) @ Id, Vgs | 5 mOhm @ 17.5A, 10V | |
| Vgs(th) (Max) @ Id | 2V @ 250µA | |
| Gate Charge (Qg) @ Vgs | 26nC @ 10V | |
| Input Capacitance (Ciss) @ Vds | 1570pF @ 13V | |
| Power - Max | 1W | |
| Mounting Type | Surface Mount | |
| Package / Case | 8-PowerTDFN | |
| Supplier Device Package | Power56 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | FDMS3610S | |
| Related Links | FDMS, FDMS3610S Datasheet, Fairchild Semiconductor Distributor | |
FDMS3610S Details Description
