Fairchild Semiconductor FDMS3686S
- Mfg. Part Number
- FDMS3686S
- Manufacturer
- Fairchild Semiconductor
- Product Category
- FETs - Arrays
- Brief Description
- MOSFET 2N-CH 30V 13A/23A 8-PQFN
- Datasheet Download
- FDMS3686S.pdf
Availability of FDMS3686S
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.60000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of FDMS3686S, we specialize in Fairchild Semiconductor all series electronic components. FDMS3686S can be shipped within 24 hours after order. If you have any demands for FDMS3686S, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- FDMS3686S Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
FDMS3686S
| Internal Part Number | EIS-FDMS3686S | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Featured Product | Cloud Systems Computing Mid- and Low-Voltage MOSFETs | |
| PCN Assembly/Origin | Wafer 6/8 Inch Addition 16/Jun/2014 | |
| Standard Package | 3,000 | |
| Category | Discrete Semiconductor Products | |
| Family | FETs - Arrays | |
| Series | PowerTrench® | |
| Packaging | Tape & Reel (TR) | |
| FET Type | 2 N-Channel (Dual) Asymmetrical | |
| FET Feature | Logic Level Gate | |
| Drain to Source Voltage (Vdss) | 30V | |
| Current - Continuous Drain (Id) @ 25°C | 13A, 23A | |
| Rds On (Max) @ Id, Vgs | 8 mOhm @ 13A, 10V | |
| Vgs(th) (Max) @ Id | 2.7V @ 250µA | |
| Gate Charge (Qg) @ Vgs | 29nC @ 10V | |
| Input Capacitance (Ciss) @ Vds | 1785pF @ 10V | |
| Power - Max | 1W | |
| Mounting Type | Surface Mount | |
| Package / Case | 8-TDFN Exposed Pad | |
| Supplier Device Package | 8-PQFN (5x6) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | FDMS3686S | |
| Related Links | FDMS, FDMS3686S Datasheet, Fairchild Semiconductor Distributor | |
