Fairchild Semiconductor FDPF12N50FT
- Mfg. Part Number
- FDPF12N50FT
- Manufacturer
- Fairchild Semiconductor
- Product Category
- FETs - Single
- Brief Description
- MOSFET N-CH 500V 11.5A TO-220F
- Datasheet Download
- FDPF12N50FT.pdf
Availability of FDPF12N50FT
Available Quantity
5520 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.77000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of FDPF12N50FT, we specialize in Fairchild Semiconductor all series electronic components. FDPF12N50FT can be shipped within 24 hours after order. If you have any demands for FDPF12N50FT, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- FDPF12N50FT Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
FDPF12N50FT
| Internal Part Number | EIS-FDPF12N50FT | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 50 | |
| Category | Discrete Semiconductor Products | |
| Family | FETs - Single | |
| Series | UniFET™ | |
| Packaging | Tube | |
| FET Type | MOSFET N-Channel, Metal Oxide | |
| FET Feature | Standard | |
| Drain to Source Voltage (Vdss) | 500V | |
| Current - Continuous Drain (Id) @ 25°C | 11.5A (Tc) | |
| Rds On (Max) @ Id, Vgs | 700 mOhm @ 6A, 10V | |
| Vgs(th) (Max) @ Id | 5V @ 250µA | |
| Gate Charge (Qg) @ Vgs | 30nC @ 10V | |
| Input Capacitance (Ciss) @ Vds | 1395pF @ 25V | |
| Power - Max | 42W | |
| Mounting Type | Through Hole | |
| Package / Case | TO-220-3 Full Pack | |
| Supplier Device Package | TO-220F | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | FDPF12N50FT | |
| Related Links | FDPF1, FDPF12N50FT Datasheet, Fairchild Semiconductor Distributor | |
FDPF12N50FT Details Description
