Hirose Electric Co Ltd FH28D-68S-0.5SH(39)
- Mfg. Part Number
- FH28D-68S-0.5SH(39)
- Manufacturer
- Hirose Electric Co Ltd
- Product Category
- FFC, FPC (Flat Flexible) Connectors
- Brief Description
- CONN FPC/FFC 68POS .5MM
- Datasheet Download
- FH28D-68S-0.5SH(39).pdf
Availability of FH28D-68S-0.5SH(39)
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.40000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of FH28D-68S-0.5SH(39), we specialize in Hirose Electric Co Ltd all series electronic components. FH28D-68S-0.5SH(39) can be shipped within 24 hours after order. If you have any demands for FH28D-68S-0.5SH(39), Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- FH28D-68S-0.5SH(39) Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
FH28D-68S-0.5SH(39)
| Internal Part Number | EIS-FH28D-68S-0.5SH(39) | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Featured Product | FH28 Series FPC/FFC Connectors | |
| Standard Package | 2,000 | |
| Category | Connectors, Interconnects | |
| Family | FFC, FPC (Flat Flexible) Connectors | |
| Series | FH28 | |
| Packaging | Tape & Reel (TR) | |
| Flat Flex Type | FFC, FPC | |
| Mounting Type | Surface Mount, Right Angle | |
| Connector/Contact Type | Contacts, Bottom | |
| Number of Positions | 68 | |
| Pitch | 0.020" (0.50mm) | |
| Termination | Solder | |
| FFC, FCB Thickness | 0.30mm | |
| Height Above Board | 0.100" (2.54mm) | |
| Locking Feature | Rotary Lock | |
| Cable End Type | Tabbed | |
| Contact Material | Phosphor Bronze | |
| Contact Finish | - | |
| Housing Material | - | |
| Actuator Material | - | |
| Features | Solder Retention, Zero Insertion Force (ZIF) | |
| Voltage Rating | 50V | |
| Operating Temperature | -40°C ~ 85°C | |
| Material Flammability Rating | - | |
| Current Rating | 0.5A | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | FH28D-68S-0.5SH(39) | |
| Related Links | FH28D-68S, FH28D-68S-0.5SH(39) Datasheet, Hirose Electric Co Ltd Distributor | |
FH28D-68S-0.5SH(39) Details Description
